Product information Product information "" Suitable for high sliding speed at low load... more
Product information "SIB-MET® Cylindrical bushing SBZ"
Product information
""Suitable for high sliding speed at low load capacity. Series production for high quantities.
SIB-MET is a self-lubricating and maintenance-free plain bearing. Suitable for high speeds at low loads.
Werkstoffe
Support material/Carrier material | CuSn10 (SINT B50) |
Produkteigenschaften
Maintenance | maintenance free |
Static load | ≤ 50 N/mm² |
Dynamic load | ≤ 5 N/mm² |
Sliding speed | ≤ 6,0 m/s |
Friction value | 0,05 up to 0,20 µ |
Temperature strain | -20 up to +100 °C |
max. pv-value | 1,6 N/mm² x m/s |
Toleranzangaben
Housing ø | H7 |
Bushing inner ø after mounting | H7 / H8 |
Shaft tolerance | f7 |
Wellenwerkstoff
Material | Steel, hardened or unhardened, surface roughness Rautiefe ≤ Rz 4 |
Montagehinweise
Installation mandrel | The use of a suitable mounting mandrel is required. It may be necessary to grease the outer surfaces during installation. |
