TECHNICAL DETAILS NOX-MET® Wrapped composite dry sliding bearing Stainless steel / PTFE... more
Product information "NOX - MET® sliding stripes NXS"
TECHNICAL DETAILS NOX-MET®
- Wrapped composite dry sliding bearing
- Stainless steel / PTFE
- DIN 1494 / ISO 3547
- Maintentance-free
- Stainless steel 1.4301 / (1.4401 on request)
- Flanged sliding bearings on request
- Also available without non-ferrous meta
Excellent sliding and wear behaviour, high load capacity, shock resistant, chemically resistant against acids and bases (ph-value 0-14), corrosion resistant
Sliding surface: | PTFE |
Support material: | Stainless steel 1.4301 (1.4401 on demand) |
Dynamic load: | ≤ 140 N/mm² |
Static load: | ≤ 250 N/mm² |
Sliding speed: | ≤ 2 m/s |
Fricition value: | 0,02 - 0,20 µ |
max. PV-value: | 1,8 N/mm² x m/s |
Temperature strain: | -200 up to +280 °C |
Maintenance: | maintenance-free |
Tolerance housing: | H7 |
Tolerance after mounting: | H9 |
Shaft tolerance: | f7 or f8 |
Shaft material: | Steel, hardened or untempered, roughness Rz < 2-3 |
